Features and Specifications:
-
Manufactured from virgin LLDPE using advanced
extrusion technology.
-
Excellent characteristics of LLDPE provide
durable tubing with close dimensional tolerances.
-
Jain Oval Hose once pressurized becomes 98%
round.
-
Suitable for surface as well as subsurface
installation.
-
UV stabilized. No environmental effects.
-
Each batch passes through following stringent
quality tests to ensure efficient and trouble free performance.
- Dimensional tolerances.
- Short term & long term hydraulic pressure.
- Heat reversion.
- Carbon black content.
- Environmental stress crack resistance (ESCR).
- Tensile Strength and Elongation.
|
-
Best environmental stress crack resistance.
-
Oval shape reduces freight and storage cost.
-
Tested as per ASAE standard.
Applications:
|
Jain Oval Hose ASAE AS435:
| Code |
Nominal Diameter |
Inside Diameter |
Min. Wall Thickness |
Std. Coil Length |
Weight per Coil |
| mm |
inch |
mm |
inch |
mm |
inch |
m |
ft |
g/m |
lbs/100ft |
|
2.9 kg/cm² (42 psi) Working Pressure |
| DOHI010021 |
10 |
- |
9.90 |
0.39 |
0.533 |
0.021 |
1006 |
3300 |
16.0 |
1.07 |
| DOHI013027 |
13 |
- |
12.70 |
0.50 |
0.686 |
0.027 |
915 |
3000 |
27.0 |
1.81 |
| DOHI016034 |
16 |
0.50 |
16.00 |
0.63 |
0.864 |
0.034 |
500 |
1640 |
43.0 |
2.88 |
| DOHI020043 |
20 |
0.75 |
20.57 |
0.81 |
1.092 |
0.043 |
366 |
1200 |
69.0 |
4.62 |
| DOHI026054 |
26 |
1.00 |
26.41 |
1.04 |
1.372 |
0.054 |
201 |
660 |
112.0 |
7.50 |
| DOHI035070 |
35 |
1.25 |
34.54 |
1.36 |
1.778 |
0.070 |
122 |
400 |
190.0 |
12.73 |
| DOHI040084 |
40 |
1.50 |
40.38 |
1.59 |
2.134 |
0.084 |
107 |
350 |
266.0 |
17.82 |
| DOHI052108 |
52 |
2.00 |
51.99 |
2.04 |
2.743 |
0.108 |
76 |
250 |
441.0 |
29.55 |
|
1.45 kg/cm² (21 psi) Working Pressure |
| DOHI026026 |
26 |
1.00 |
26.41 |
1.04 |
0.660 |
0.026 |
506 |
1660 |
52.0 |
3.48 |
| DOHI035034 |
35 |
1.25 |
34.54 |
1.37 |
0.864 |
0.034 |
244 |
800 |
90.0 |
6.03 |
| DOHI040040 |
40 |
1.50 |
40.38 |
1.60 |
1.016 |
0.040 |
183 |
600 |
123.0 |
8.24 |
| DOHI052051 |
52 |
2.00 |
51.99 |
2.05 |
1.295 |
0.051 |
137 |
450 |
203.0 |
13.60 |
| DOHI077075 |
77 |
3.00 |
77.16 |
3.03 |
1.930 |
0.075 |
61 |
200 |
448.0 |
30.01 |
| DOHI101100 |
101 |
4.00 |
101.37 |
3.99 |
2.540 |
0.100 |
40 |
131 |
775.0 |
51.92 |
1.13 kg/cm² (16 psi) Working Pressure |
| DOHI151108 |
151 |
6.00 |
151.30 |
5.95 |
2.760 |
0.108 |
30 |
100 |
1250.00 |
83.75 |
| Note : Inside Diameter based Hose. |
|
|
Jain Oval Hose once pressurized becomes 98%
round.
Ordering Specifications:
Example: DOHI016034M500 - This code refers to Jain Oval Hose of nominal diameter 16 mm having wall thickness 0.034” with standard coil length of 500 m.
Note: - Please refer standard specification table while ordering.
- On request, Jain Oval Hose can be supplied in any other length than standard coil length
|
|
|
|
 |
|
